M-TRACK DUO M-AUDIO
M-TRACK DUO M-AUDIO
Hurry up! Only 1 items in stock.
Couldn't load pickup availability
Main features
- 2-channel USB recording interface for Mac and PC
- (2) Combo Inputs with Crystal Preamps incredible audio quality
- Dedicated switches to activate any microphone, instrument or line-level device
- +48V phantom power for connecting studio condenser microphones
- 1/4" stereo outputs; 1/4" headphone output with independent level controls
- USB/Direct Mono/Direct Stereo switch to control mic, line or instrument inputs in stereo or mono
- Software bundle including: MPC Beats, AIR Music Tech Electric, Bassline and TubeSynth, Revalver guitar amp plug-in and 80 AIR effects plug-ins
Technical specifications
|
Microphone input (balanced XLR) |
|
|
Response frequency |
20 Hz – 20 kHz (+0.1 dB) |
|
Signal to noise ratio |
109 dB (A-weighted) |
|
THD+N |
0.003% (min gain, 0 dBu output, A-weighted) |
|
EIN Preamp |
-128 dBu (max gain, 40 Ω source, A-weighted) |
|
Gain range |
Direct mono: 0 dB to +54 dB Direct stereo: 6 dB to +60 dB |
|
Line Input (Balanced 1/4" [6.35 mm] TRS) |
|
|
Response frequency |
20 Hz – 20 kHz (+0.1 dB) |
|
Sensitivity |
-43 dBu |
|
THD |
0.002% (min gain, 0 dBu output, A-weighted) |
|
Gain range |
Direct mono: -10 dB to +44 dB Direct stereo: -4 dB to +50 dB |
|
Instrument Input (1/4" [6.35 mm] unbalanced TS) |
|
|
Response frequency |
20 Hz – 20 kHz (+0.1 dB) |
|
THD+N |
0.005% (min gain, 0 dBu output, A-weighted) |
|
Input impedance |
1 MΩ |
|
Gain range |
Direct mono: -10 dB to +44 dB Direct stereo: -4 dB to +50 dB |
|
Main outputs, L and R (impedance balanced 1/4" [6.35 mm] TRS) |
|
|
Response frequency |
20 Hz – 20 kHz (+0.1 dB) |
|
Signal to noise ratio |
109 dB (A-weighted) |
|
THD |
0.002% (0 dBu output, A-weighted) |
|
Maximum output level |
+4 dBu |
|
Headphone output (1/4" [6.35 mm] TRS) |
|
|
Power |
60 mW/Ch, 32 Ω |
|
Response frequency |
20 Hz – 20 kHz (+0.5 dB) |
|
THD+N |
0.02% (A-weighted) |
|
Signal to noise ratio |
100 dB (A-weighted) |
