Les mélangeurs compacts Mackie Mix offrent la qualité que vous attendez. Les mélangeurs professionnels et abordables de la série Mix présentent des composants de haute qualité, un châssis en métal robuste et des fonctionnalités conçues pour diverses applications.
Series Specifications:
Noise Characteristics
(20 Hz – 20 kHz bandwidth, 150
source impedance)
All outputs, master levels and channel levels off
–100 dBu
All outputs, master levels unity, all channel levels off
–90 dBu
All outputs, master levels unity, 1 channel level unity
–85 dBu
Distortion (THD+N)
(1 kHz, 20 Hz – 20 kHz bandwidth)
Mic Input to Main Output
<0.01% @+4 dBu output
Attenuation and Crosstalk
(20 Hz–20 kHz bandwidth)
Inputs to Outputs @ 1 kHz
–85 dB
Main Mix Off @ 1 kHz
–80 dB
Frequency Response
Mic input to any output (gain @ unity) +0, –1 dB, 20 Hz to 30 kHz
Equivalent Input Noise (EIN)
(Mic in to Insert Send out, max gain.)
150
termination
–125 dBu [Mix5, Mix8]
–122 dBu [Mix12FX]
Common Mode Rejection Ratio (CMRR)
(Mic in to Insert Send out, max gain.)
1 kHz
better than 70 dB
Maximum Levels
Mic inputs (XLR)
+18 dBu [Mix5]
+19 dBu [Mix8, Mix12FX]
Aux return in
+16 dBu [Mix8]
All other inputs
+21 dBu
All outputs
+21 dBu
Impedances
Mic in
2 k
[Mix5]
3.8 k
[Mix8, Mix12FX]
All other inputs
10 k
or greater
Tape out
1 k
Phones out
22
All other outputs
120
unbalanced,
240
balanced
EQ
High Shelving
±15 dB @ 12 kHz
Mid Peaking
±15 dB @ 2.5 kHz
Low Shelving
±15 dB @ 80 Hz
Low Cut Filter
18 dB/octave, –3 dB @ 75 Hz
