SIGMA-X12 WHARFEDALE PRO

Name: SIGMA-X12 WHARFEDALE PRO
Brand: INTELLIMIX
Price: 574.99 CAD
Availability: OutOfStock

$574.99 CAD

Frais d'expédition calculés à l'étape de paiement.

En rupture, on peut vérifié chez le fournisseur ;-)

Promo des fêtes !!!

00 Jours

00 Heures

00 Minutes

00 Secondes

S'appuyant sur les performances fiables de la série SIGMA, le nouveau SIGMA-X est doté de grilles avant et de matériaux de support nouvellement conçus pour une installation tout simplement superbe. Disponibles en finition peinture noire ou blanche durable , les modèles SIGMA-X incluent désormais également des connexions SpeakON et des bandes de protection, ce qui facilite l'installation ! Des options de montage et de montage améliorées rendent le SIGMA-X simple à installer dans presque tous les endroits. La définition audio améliorée est également la bienvenue, car le SIGMA-X a été entièrement réévalué par l'équipe R&D de Wharfedale Pro International.

300 W AES (Continuous)
600 W Programme
1200 W Peak
129 dB Max SPL @ 1 m

Model Name	SIGMA-X8	SIGMA-X10	SIGMA-X12	SIGMA-X15	SIGMA-X18B
System Type	Passive	Passive	Passive	Passive	Passive
Configuration	Two-Way	Two-Way	Two-Way	Two-Way	Subwoofer
Frequency Response (+/-3 dB)	70 Hz – 18 KHz	65 Hz – 18 KHz	60 Hz – 18 KHz	50 Hz – 18 KHz	35 Hz – 250 Hz
Frequency Range (-10 dB)	65 Hz – 20 KHz	60 Hz – 20 KHz	55 Hz – 20 KHz	45 Hz – 20 KHz	30 Hz – 250 Hz
Sensitivity 2.83 V / 1 m	96 dB	97 dB	98 dB	98 dB	100 dB
Calculated Maximum SPL @1 m	124 dB	126 dB	129 dB	129 dB	133 dB
System Rated Impedance	8 Ω	8 Ω	8 Ω	8 Ω	4 Ω
Low Frequency Transducer
Size (mm / inches)	203 mm / 8”	254 mm / 10”	305 mm / 12”	381 mm / 15”	457 mm / 18”
Voice Coil Size (mm / inches)	38 mm / 1.5”	38 mm / 1.5”	64 mm / 2.5”	64 mm / 2.5”	64 mm / 2.5”
Rated Impedance	8 Ω	8 Ω	8 Ω	8 Ω	4 Ω
LF Power re:AES2-2012	150 W	200 W	300 W	350 W	500 W
High Frequency Transducer
HF Driver Type	Compression Driver	Compression Driver	Compression Driver	Compression Driver	n/a
Coil Size (mm / inches)	44 mm / 1.75”	44 mm / 1.75”	44 mm / 1.75”	44 mm / 1.75”	n/a
Exit Size (mm / inches)	1″	1″	1″	1″	n/a
Diaphragm Material	Titanium	Titanium	Titanium	Titanium	n/a
Rated Impedance	8 Ω	8 Ω	8 Ω	8 Ω	n/a
HF Power re:AES2-2012	40 W	40 W	40 W	40 W	n/a
Waveguide Type	Constant Directivity / Rotatable	Constant Directivity / Rotatable	Constant Directivity / Rotatable	Constant Directivity / Rotatable
Nominal Coverage (H x V)	90˚ x 60˚	90˚ x 60˚	90˚ x 60˚	90˚ x 60˚	na
LF Driver	1 x 8″	1 x 10″	1 x 12″	1 x 15″	1 x 18″
HF Driver	1 x 1.75″ Titanium Compression Driver	1 x 1.75″ Titanium Compression Driver	1 x 1.75″ Titanium Compression Driver	1 x 1.75″ Titanium Compression Driver	n/a
Power
System Continuous Power	150 W	200 W	300 W	350 W	500 W
System Programme Power	300 W	400 W	600 W	700 W	1000 W
System Peak Power	600 W	800 W	1200 W	1400 W	2000 W
Crossover frequency	2.8 KHz	2.4 KHz	2.2 KHz	2.2 KHz	150 Hz
Recommended HPF = BW 18 dB/oct.	55 Hz	45 Hz	38 Hz	33 Hz	28 Hz
Input Connector	2 x speakON / 1x Barrier Strip	2 x speakON / 1x Barrier Strip	2 x speakON / 1x Barrier Strip	2 x speakON / 1x Barrier Strip	2 x speakON / 1x Barrier Strip
Hardware	35 mm pole socket	Dual-angle (0° /10°) 35 mm socket	Dual-angle (0° / 10°) 35 mm socket	Dual-angle (0° / 10°) 35 mm socket	35 mm pole socket
	M8 x 17	M8 x 17	M8 x 17	M8 x 17
	1 handle on back	1 handle on back	1 handle on back	2 handles on sides	4 handles on sides
Enclosure
Enclosure Material	15 mm MDF	15 mm MDF	15 mm MDF	15 mm MDF	18 mm MDF
Finish	Black Paint / White Paint	Black Paint / White Paint	Black Paint / White Paint	Black Paint / White Paint	Black Paint / White Paint
Grille Material & Finish	1.2 mm steel, painted	1.2 mm steel, painted	1.2 mm steel, painted	1.2 mm steel, painted	1.2 mm steel, painted
Dimensions – Unpacked
Height	465 mm / 18.3″	520 mm / 20.5″	551 mm / 21.7″	650 mm / 25.6″	554 mm / 21.25″
Width Front	284 mm / 11.2″	338 mm / 13.3″	354 mm / 14″	435 mm / 17″	502 mm / 20″
Width Rear	176 mm / 6.9″	213 mm / 8.4″	218 mm / 8″	261 mm / 11.7″	502 mm / 20″
Depth	282.7 mm / 11.1″	338.3 mm / 13.3″	359 mm / 14″	439 mm / 17.25″	780 mm / 30.8″
Dimensions – Packed
Height	505 mm / 19.9″	585 mm / 23″	616 mm / 24.3″	715 mm / 28.1″	649 mm / 25.5″
Width Front	364 mm / 14.3″	441 mm / 17.3″	468 mm / 18.4″	553 mm / 21.75″	588 mm / 22.75″
Width Rear	214.4 mm / 8.43″	251 mm / 9.9″	260 mm / 10.2″	304 mm / 12″	588 mm / 22.75″
Depth	333 mm / 13.1″	389 mm / 15.3″	404 mm / 15.9″	488 mm / 19.2″	865 mm / 34″
Weight
Net Weight	12.2 kg / 26.8 lbs	17.1 kg / 37.62 lbs	19.1 kg / 42.02 lbs	24.4 kg / 53.7 lbs	39.1 kg / 86 lbs
Gross Weight	13.5 kg / 29.7 lbs	18.8 kg / 41.4 lbs	20.74 kg / 48.2 lbs	27.7 kg / 60.9 lbs	46.4 kg / 102 lbs
Optional Wall-mount bracket	WPB-1 / WPB-2	WPB-1 / WPB-2	WPB-1 / WPB-2	WPB-1 / WPB-2	n/a
